Alusong Cladding - SPRECTRA

Alusong Cladding - SPRECTRA

ALUSONG Spectra aluminum composite panel are named as its changing color illusion and the surface of the panels can present a variety of pleasing colors following the change of the light and perspective. The spectra patterns series was through special processing, take the national cultural into interior decoration, and blend into harmonious ...
分享
0
  • 颜色和表面
  • 产品范围
  • 产品属性
  • 产品应用
  • 技术数据
颜色和表面

ALUSONG Spectra colors coating, add pearl talc into PVDF paint(>70% PVDF), depending upon the pigment type and viewing angle, different wavelengths of light are reflected, refracted and diffracted to the audience resulting in an ever-changing color gradient with iridescent highlights. It is widely used for public internal and external, multiply shops, exhibitions etc.


Raw material:

Base material: high strength aluminum alloy sheet

PE core material: non-toxic low density polyethylene

Surface coating: spectra coating

Back coating: primer coating



产品范围
Aluminum alloyAA1100  AA3003 AA5005
Aluminum skin0.21mm,0.30mm,0.35mm,0.40mm,0.45mm,0.5mm
Panel thickness3mm,4mm,5mm,6mm
Panel width1220mm,1250mm,1500mm
Panel length2440mm,3050mm,4050mm
Surface treatmentSPECTRA
Colors70 colors, RAL & PANTONE colors upon request
Customers sizeaccepted
GLOSSY40%-80%


Panel width: ±2mm        Panel length:±3mm

Panel thickness: ±0.2mm    Panel diagonal: ≤5mm

Aluminum sheet thickness: ±0.02mm


产品属性
Alusong Cladding - SPRECTRA

Optional

In accordance with optical elements, the spectra aluminum composite panel use the light’s reflection, diffraction, refraction and absorption. These color effects have fascinated motivated, triggered emotions and had an effect on man’s feeling since time immemorial.

Sensory Theme

Depending on the type of pigment and viewpoint, different, color enchanting effects with highlights and color iridescent gradients appear.

Design exertion

The special aluminum composite panel has a series of glosses and sharps to meet the designer’s needs of originality of design, and achievers perfect results.


产品应用

1. Wall curtain, Cladding and Facade

2. 4s car shops,commercial malls

3. Modern buildings


技术数据
DescriptionSpectra
Coating rididity≥2H
Coating flexibility (T-bend)2T
Boiling water resistanceNo change after 24hours
Alkali resistanceNo change
Acid resistanceNo change
Solvent resistanceNo change
Washing resistanceNo change after 1000 times
